TGU shaft hanger-set - PU = 25 pcs
PU (Pcs): 25
Application:1. Fast, easy replacement of broken shaft hangers.2. Sturdy and durable components for new and old greenhouses.3. Designed to fit most greenhouses, it can also be customized on demand.Benefits:• Less labor on repairs. No need to dismantle the shaft, our unique hangers are assembled around it - it’s a one-man job!• Adds flexibility to the construction of new systems in existing and new buildings.• Extends the life of other related parts (motors, drive pipes, structure stability) due to the specially formulated inner plastic ring which serves as bearing support and holds the drive line in its optimal position.• A better alternative to a standard support plate and other shaft hangers.• Makes complicated drive line repairs easy!
0,00 €*
Pillow block 1" with bearing
Bearing: 6207 ZZ
The pillow block with a double-shell stamped metal bracket works as a support point for 34 mm drive shafts for ventilation- and shading-systems in greenhouses. The pillow block has mounting holes for M8 bolts.Thanks to its double-shell construction the ball bearing within the bracket can be replaced, if needed. The product can be delivered with a usual ball bearing SB 207 (24000101) or with a ball bearing with a longer inner ring UB 207 (24000101).Material: Galvanized steel (housing & bearing)
0,00 €*
Steel tube, galv narrowed
PU: Bunch
This steel tube is particular stable. It is used as a push-pull-tube for shading- and ventilation systems in greenhouses. The tubes can be easily connected by inserting them into each other through their swaged ends and bolting them afterwards. Bolt and nut 27.32 for steel tubes are needed.Diameter: 32 mm Wall thickness: 1.5 mm Length: 6500 mm Material: Galvanized Steel
0,00 €*
Slide bearing plate straight B1'' - B1\B077\L107
Length: B077\L107 | Version: Straight
Mounting height: Lower edge to middle of drive shaft 77 mmRidder Art.-Nr.: 503095
0,00 €*
Tube connectors halfs 1" - incl. 4 bolts M8 x 45 - PU = 25 Sets
PU: 25
These tube connector halves are used for reliable connection of 34 mm steel tubes for drive shafts. Compared to heat-welded connection our tube connector halves offer higher stability and durability. The connector halves are bolted to the steel tubes with the included M8x50 bolts. Material: Steel, galvanized
0,00 €*
Steel tube galv. narrowed, 1'' / 2,5mm - L= 6,50 m - Bundle = 81pcs
PU: Bunch
This steel tube is used as a drive shaft for ventilation systems and large shading systems in greenhouses.Due to its wall-thickness of 2,50 mm, it is resistant against torsion.The tubes can be easily connected by inserting them into each other through their swaged ends and bolting them afterwards. Bolt M8 x 50 with a nyloc nut M8 are neededDiameter: 1 Wall thickness: 2.5 mmLength: 6500 mmMaterial: Galvanised Steel
0,00 €*
Coupling unit PH40\B27x1.5\ST - to connect rack PH 40-3 with push-pull tube d. 27 mm
Size Ø: 27
Ridder "connector set" for acks and push-pull tubes in shading systems.Suitable for 27 racks. Material: pressure casting galvanized - Ridder Art.-Nr.: 500208
0,00 €*
Steel tube, galvanized 1"
PU: Bunch
This steel tube is used as a drive shaft in shading and ventilation systems in large greenhouses. Due to its wall thickness of 3.25 mm, it is very resistant against torsion. The tube connector halves within our product range are used to connect the tubes. Diameter: 33.5 mm Wall thickness: 3,25 mm Length: 6050 mm Material: Steel, galvanized
0,00 €*
Aluminum tube for rollup curtains 50 mm Type 1 L=6,40 m - 86 pcs/ Bundle
Length (cm): 640 | PU: Bunch
Das ideale Rollschirmrohr für Single-Rollschirme. Es ist ausgestattet mit einer Nut zum Einführen des Gewebes.Material: Aluminium
0,00 €*
Steel tube, galvanized swaged
PU: loose
This steel tube is particular stable. It is used as a push-pull-tube for shading- and ventilation systems in greenhouses. The tubes can be easily connected by inserting them into each other through their swaged ends and bolting them afterwards. Bolt and nut 27.32 for steel tubes are needed.Diameter: 27 mm Wall thickness: 1.5 mm Length: 6500 mm Material: Galvanized Steel
0,00 €*
aluminum splice for rollup 230 mm, 50mm - PU = 85 pcs
The splices are getting inserted into the roll-up tube. Aluminium rivets provide a reliable hold. The splices are compatible with aluminium tube 50 type I and II. Material: aluminium
0,00 €*
Sleeve coupling P26.5
This sleeve coupling is suitable for the drive shafts of 34 mm in push-pull drive tubes in shading and ventilation systems. It enables to unclamp the drive shaft from the system in case, for example, a damaged pinion should be replaced.. Material: galvanized steelRidder Art.-Nr.: 419404
0,00 €*
Support plate Fiberlane 1" - 105 - Height: 105 mm - Lower edge to middle of drive shaft 67 mm
Height (mm): 105
This high quality support plate from TGU works as a bearing for 34 mm drive shafts in ventilation systems in greenhouses. It has straight mounting holes. This support plate is especially durable even under heavy weights thanks to a slide bearing, which is fitted with a special plastic ring. This bearing offers perfect slide effects and works as a substitute for grease. Material: Galvanized steelMounting height: Lower edge to middle of drive shaft 67 mm
0,00 €*
Weld/sleeve coupling 1" - for 1" - tubular shaft P26.5\B1\L40\WELD
This weld coupling for pinion house unit RSD 250 suitable for steel tubes 1.315" or 1.66" is used in push-pull tube drives in shading and ventilation systems. Material: galvanized steelRidder Art.-Nr.: 401635
0,00 €*
Clamping strip, PVC - 2-parts - L=2 m - PU = 100 pcs
Version: FN 19
This clamping strip is used to fix the greenhouse film to the aluminium Poly Lock Profile.
0,00 €*
Film clip 27.59 - PU = 900 pcs
Version: 27.59
Our film clips are used in roll up screens for fixing film and fabrics onto 27 mm steel tubes, that can be alternative to aluminium grooved ones.The clips are made of plastic, which is friendly to any component of roll up screens.
0,00 €*
U-joint 5/4"
Universal joint for attaching 5/4" tubular drive shafts to each other by welding
0,00 €*
Slide bearing plate straight B5/4'' - B5/4\B055\L090
Length: B055\L090 | Version: Straight
The support plate works as a bearing for 42 mm drive shafts in greenhouses. It is equipped with straight mounting holes. Thanks to built-in slide bearing, which is constructed with a centred bronze ring, this support plate is very durable and suitable for applications under heavy weights. In addition this slide bearing functions as a substitute for grease. Material: Galvanized steelMounting height: Lower edge to middle of drive shaft 55 mmRidder Art.-Nr.: 503200
